Handle

Handle assembly details for Stiga SRC 775 RB [212751122-14] 2017 model

Parts list

Match the number with the image on the left and click "Add" button to add the item to your basket

Please note, that the prices are for individual items

Items might appear more than once on the drawing, please check and adjust the quantity you require.

Ref	No	Description	Price
001	118802984/0	CLUTCH LEVER	£35.74	Add to
002	118802982/0	CLUTCH CABLE	£39.21	Add to
003	118802977/0	PANEL [YELLOW]	£20.49	Add to
004	1483-2213-01	HANDLE GRIP	£4.90	Add to
005	9948-0655-16	SCREW	£2.06	Add to
006	1483-2143-01	ACCELERATOR	N/A	POA
007	112154510/0	LOW SELF-LOCKING NUT M6 UNI7474 ACC.6S	£2.06	Add to
008	118802969/0	THROTTLE CABLE	£15.84	Add to
009	118802985/0	CLUTCH LEVER-REVERSE	£35.74	Add to
010	118802983/0	CLUTCH LEVER-REVERSE	£33.16	Add to
011	118802979/0	HANDLE	£90.98	Add to
012	1483-2044-01	LEVER	N/A	POA
013	1483-2279-01	KNOB	N/A	POA
014	1483-2073-01	WASHER	N/A	POA
015	118802980/0	HANDLE REINFORCEMENT	N/A	POA
016	9699-0121-02	WASHER	£2.06	Add to
017	9747-1231-02	NUT	£2.06	Add to
018	112691900/0	HEX-HEAD SCREW	£1.91	Add to
019	1483-2021-01	WIRE SUPPORT PLATE - NLA	£2.14	Add to
020	112293201/0	HEXAGON NUT M8 WITH EXAGONAL FLANGE	£2.06	Add to
021	112793701/0	HEX-HEAD SCREW M8 x 30	£1.76	Add to
022	118803004/0	LEVER KNOB	£5.73	Add to
023	9699-0122-02	WASHER 9 x 28 x 2	£2.06	Add to
024	1483-2166-01	CAP	£2.87	Add to
025	118803012/0	NUT	N/A	POA
026	118802978/0	COVER [YELLOW]	£27.27	Add to
027	112789350/0	SCREW	N/A	POA
028	112154330/0	LOW SELF-LOCKING NUT M5	£2.06	Add to
029	118802974/0	TRANSMISSION	£504.15	Add to
030	1483-2186-01	CAP	£4.52	Add to
031	1483-2187-01	OIL SEAL	£5.52	Add to
032	9598-0002-02	SPRING PIN 2.5mm L=47mm	£2.06	Add to
033	118802986/0	DEPTH SKID	£22.29	Add to
034	112521390/0	WASHER M16 17 x 30 x 3	£1.91	Add to
035	112293201/0	HEXAGON NUT M8 WITH EXAGONAL FLANGE	£2.06	Add to
036	9997-0855-12	USE 112691700/0	£2.74	Add to
037	118802988/0	GUARD PLATE	£86.13	Add to
038	118802989/0	GUARD EXTENSION	£32.99	Add to
039	9959-0616-16	SCREW M6SF M6 X 16	£2.06	Add to
040	118803014/0	WASHER	N/A	POA
041	1134-3643-01	NUT	£13.23	Add to
042	1483-2075-01	CAP	£4.10	Add to
043	118802987/0	WHEEL SUPPORT	£30.26	Add to
044	118802972/0	WHEEL	£25.28	Add to
045	118802971/0	SPRING	£6.14	Add to
046	118803017/0	SPLIT PIN	£4.23	Add to
047	112521390/0	WASHER M16 17 x 30 x 3	£1.91	Add to
048	1483-2195-01	LOCK WASHER	£3.83	Add to
049	1483-2070-01	OIL SEAL	£8.32	Add to
050	118802992/0	DUST COVER	£6.42	Add to
051	9997-1050-16	SCREW M6S M10 x 50	£2.87	Add to
052	1483-2196-01	LOCK PIN	£3.41	Add to
053	112156602/0	LOW SELF-LOCKING NUT M10	£1.79	Add to
054	1483-2023-01	R/H TINE ASSEMBLY	£82.05	Add to
054	1483-2024-01	L/H TINE ASSEMBLY	£82.05	Add to
055	1483-2169-01	TINE ASSY OUTER-RH	£67.05	Add to
055	1483-2170-01	TINE ASSY OUTER-LH	£68.42	Add to
056	9997-1050-16	SCREW M6S M10 x 50	£2.87	Add to
057	112156602/0	LOW SELF-LOCKING NUT M10	£1.79	Add to
061	1483-2022-01	PROTECTION DISC	£34.35	Add to
