TRANSMISSION

TRANSMISSION assembly details for Stiga 13-7823-24 TITAN RM135H COMBI DECK 2014 model

Parts list

Match the number with the image on the left and click "Add" button to add the item to your basket

Please note, that the prices are for individual items

Items might appear more than once on the drawing, please check and adjust the quantity you require.

RefNoDescriptionPrice
0011134-7406-01TRANSMISSION COVER£211.50 Add to
0021134-7407-01TRANSMISSION COVER L/H£84.70 Add to
0031134-7408-01TRANSMISSION COVER R/H£55.26 Add to
0041134-7280-01TRANSMISSION COVER L/H£177.70 Add to
0051134-7280-02TRANSMISSION COVER R/H£177.70 Add to
006112793102/0SCREW TE M8x20 UNI 5739 ACC.8.8£2.06 Add to
0079893-0616-16SCREW M6 x 16£2.47 Add to
008112692080/0HEX-HEAD SCREW M8 x 90£2.06 Add to
0099924-0830-16SCREW MF6S M8 x 30£2.06 Add to
010112293201/0HEXAGON NUT M8 WITH EXAGONAL FLANGE£2.06 Add to
0111134-7062-01MOTOR PLATE£118.55 Add to
0129959-1025-16SCREW M6SF M10 x 25 TL£3.00 Add to
0131134-7068-01PLATE ASSEMBLY [135H]£300.88 Add to
0149959-1020-16SCREW M6SF M10 x 20 TL£2.87 Add to
0159739-1031-22NUT M10£2.32 Add to
0161134-6979-01DOUBLE BELT PULLEY£163.80 Add to
0171134-7518-01PLASTIC PLUG£3.55 Add to
018112521350/0WASHER M8 8.4 x 16 x 1.6£2.06 Add to
0191134-7411-01WASHER£3.55 Add to
0209600-0170-00KEY£3.15 Add to
0231134-7814-01BELT PULLEY D=164mm£118.55 Add to
0241134-7815-01BELT PULLEY D=148mm£88.85 Add to
0259747-2031-02NUT M20£3.15 Add to
0261134-7124-01TENSION PULLEY D=109mm£84.77 Add to
0279959-1025-16SCREW M6SF M10 x 25 TL£3.00 Add to
0281134-5406-01WASHER M10 10.5 x 35 x 5£4.23 Add to
029112379511/0STRAIGHT GREASE NIPPLE M6 x 1£2.06 Add to
0291134-7302-01BELT TENSIONER L/H£97.03 Add to
030112379511/0STRAIGHT GREASE NIPPLE M6 x 1£2.06 Add to
0301134-7303-01BELT TENSIONER R/H£97.03 Add to
0311134-7393-01SPRING£6.42 Add to
0321134-0240-01SCREW£9.82 Add to
033112293201/0HEXAGON NUT M8 WITH EXAGONAL FLANGE£2.06 Add to
0341134-7307-01PLATE ASSEMBLY£77.00 Add to
0359924-1025-16SCREW£3.64 Add to
0369739-1031-22NUT M10£2.32 Add to
0379585-0178-01DOUBLE V-BELT£165.06 Add to
0389585-0182-01DRIVE BELT [135B/H]£44.47 Add to
