TRANSMISSION

TRANSMISSION assembly details for Stiga 13-5811-51 VILLA 78cm (320 HST) DECK 2014 model

Match the number with the image on the left and click "Add" button to add the item to your basket

Please note, that the prices are for individual items

Items might appear more than once on the drawing, please check and adjust the quantity you require.

Ref	No	Description	Price
001	1134-6613-01	BEARING BOX & SHAFT ASSEMBLY	£133.57	Add to
002	9945-0825-16	SCREW M6SF M8 x 25	£2.32	Add to
003	1134-9129-01	BLADE BAR ASSEMBLY [2 PCS]	£103.58	Add to
004	1134-9130-01	BLADE TIP KIT [2 PCS]	£33.94	Add to
005	1134-9054-01	SHEAR BOLT KIT [6 x Bolts & Nuts]	£8.84	Add to
006	1134-6311-01	BOLT 7/16" UNF	£3.24	Add to
007	1134-6312-01	LOCK NUT 7/16" UNF	£2.87	Add to
008	1134-6211-01	BLADE WASHER	£3.55	Add to
009	112794900/0	HEX-HEAD SCREW M10 x 50	£2.06	Add to
010	1134-6590-01	MULCH PLUG	£37.26	Add to
011	9959-0820-16	FLANGED SCREW M8 x 20 8.8 DIN 6921	£2.06	Add to
012	1134-0341-01	WASHER	£7.10	Add to
013	1137-0155-01	SPACER	£4.52	Add to
021	1137-1014-01	TRANSMISSION COVER	£37.08	Add to
022	1134-0240-00	SCREW	£9.14	Add to
023	1137-0155-01	SPACER	£4.52	Add to
024	9893-0616-16	SCREW M6 x 16	£2.47	Add to
025	1134-9137-01	TOOTHED BELT PULLEY [2 PCS]	£63.60	Add to
026	1137-0950-01	BELT PULLEY	£26.18	Add to
027	9600-0168-01	KEY	£4.52	Add to
028	1134-5124-02	SPACER	£5.32	Add to
029	1134-5406-01	WASHER M10 10.5 x 35 x 5	£4.23	Add to
030	112691400/0	HEX-HEAD SCREW M8 X 50	£1.76	Add to
031	1134-9133-01	TOOTHED BELT	£34.35	Add to
032	1134-9169-01	DECK BELT (VILLA 320)	£34.35	Add to
033	1134-7017-01	BELT GUIDE (OBSOLETE) (OBSOLETE)	N/A
034	9959-0820-16	FLANGED SCREW M8 x 20 8.8 DIN 6921	£2.06	Add to
035	1137-0155-01	SPACER	£4.52	Add to
037	112523060/0	WASHER M8 8.4 X 24 X 2	£2.06	Add to
038	1137-1016-01	BELT COVER	£10.53	Add to
039	9675-0016-02	STARLOCK WASHER D=11	£1.79	Add to
040	1134-0240-00	SCREW	£9.14	Add to
041	1134-4620-02	SPRING NUT	£8.32	Add to
