FRAME assembly details for Stiga 13-5821-71 VILLA 90cm (520 HST) DECK 2013 model

Parts list

Match the number with the image on the left and click "Add" button to add the item to your basket

Please note, that the prices are for individual items

Items might appear more than once on the drawing, please check and adjust the quantity you require.

0011137-0962-01DECK CASING [VILLA 520]£408.94 Add to
0021137-0969-01HOLDER LH£10.74 Add to
0031137-0969-02HOLDER RH£10.74 Add to
0049959-0820-16SCREW M6SF M8 x 20 TL£2.90 Add to
0051137-0155-01SPACER£5.17 Add to
0061137-0929-01LIFTING WIRE BRACKET£7.04 Add to
0071137-0974-01MOUNTING FRAME£76.86 Add to
0081134-0240-00SCREW£9.45 Add to
009112154220/0SELF-LOCK NUT M8£2.90 Add to
0101137-1030-01FRONT WHEEL AXLE£144.81 Add to
0111134-9139-01SUPPORT WHEEL KIT£72.47 Add to
0121134-0068-00BUSH£5.42 Add to
013112609260/0CIRCLIP D=20£2.77 Add to
0141137-0966-01FRONT TUBE BRACKET LH£8.68 Add to
0151137-0966-02FRONT TUBE BRACKET LH£8.68 Add to
0169959-0820-16SCREW M6SF M8 x 20 TL£2.90 Add to
0171137-0155-01SPACER£5.17 Add to
0181134-0240-00SCREW£9.45 Add to
019112154220/0SELF-LOCK NUT M8£2.90 Add to
0201137-0983-01PUSH ROD-HEIGHT ADJUST POINTER£21.84 Add to
0211137-0985-01STRUT£11.20 Add to
0229599-0054-02SPLIT PIN£3.15 Add to
023112604903/0STARLOCK WASHER D=10£2.90 Add to
0241137-0984-01BRACKET ASSEMBLY£42.84 Add to
0251134-5127-01WASHER£5.17 Add to
026112793905/0HEX-HEAD SCREW M8 x 70£3.15 Add to
0279959-0820-16SCREW M6SF M8 x 20 TL£2.90 Add to
0281137-0155-01SPACER£5.17 Add to
0291137-0973-01PIVOT ARM£7.58 Add to
0301134-6417-02ELECTRIC LIFTER£234.36 Add to
0311134-6373-01ROD END£35.51 Add to
032387149300/02 POLE FM MALE CONNECTOR ASSY L=835£30.64 Add to
0331134-6182-01MALE TERMINAL£24.07 Add to
0349646-0098-22RIVET 8 x 32£3.65 Add to
0351134-0041-04BUSH£11.59 Add to
036112604899/0STARLOCK WASHER RPCO 308 D=8£2.90 Add to
0401137-1019-01BRACKET£8.43 Add to
0419959-0820-16SCREW M6SF M8 x 20 TL£2.90 Add to
0421137-0155-01SPACER£5.17 Add to
0431137-1022-01FASTENER PLATE£10.74 Add to
0441137-1025-01SPRING£5.17 Add to
0451134-1565-16SPACER£7.81 Add to
0469997-0840-16SCREW M6S M8 x 40£2.90 Add to
047112154220/0SELF-LOCK NUT M8£2.90 Add to
