Transmission

Transmission assembly details for Stiga SWEEPER PARK HYDRAULIC 13-3929-11 2016 model

Match the number with the image on the left and click "Add" button to add the item to your basket

Please note, that the prices are for individual items

Items might appear more than once on the drawing, please check and adjust the quantity you require.

Ref	No	Description	Price
001	1134-9101-01	DECK DRIVE BELT 4WD	£49.34	Add to
002	1137-0071-01	HYDRAULIC CYLINDER	£368.20	Add to
047	112793102/0	SCREW TE M8x20 UNI 5739 ACC.8.8	£2.06	Add to
069	1319-1846-01	PULLEY	£80.68	Add to
071	1134-4176-01	CLIP	£5.19	Add to
074	1134-2796-02	BOLT (355 MM)	£39.22	Add to
078	1319-1825-01	BRUSH SHAFT	£211.40	Add to
079	1319-2333-01	FLANGE	£23.39	Add to
087	1134-3880-01	BRUSH	£15.13	Add to
088	1134-3884-01	BRUSH	£16.62	Add to
098	9997-1040-16	SCREW M6S 10 x 40	£7.23	Add to
100	9997-1035-16	SCREW M6S M10 x 35	£3.28	Add to
103	1319-1952-01	GEARBOX ASSEMBLY	£842.54	Add to
123	9599-0083-02	SPLIT PIN	£5.32	Add to
125	1319-2339-01	HYDRAULIC HOSES KIT	£184.24	Add to
