Steering Wheel

Steering Wheel assembly details for Stiga Stiga Park Pro 340 IX 13-6451-11 2016 model

Match the number with the image on the left and click "Add" button to add the item to your basket

Please note, that the prices are for individual items

Items might appear more than once on the drawing, please check and adjust the quantity you require.

Ref	No	Description	Price
001	337961200/0	STEERING WHEEL [BLACK]	£287.40	Add to
002	337580550/0	STEERING WHEEL PLATE	£8.75	Add to
003	112793102/0	SCREW TE M8x20 UNI 5739 ACC.8.8	£2.06	Add to
004	112583500/0	WASHER M8 UNI 1751 WZ	£2.06	Add to
005	112620299/0	SPIROL FLEXIBLE PIN 6 x 45	£1.91	Add to
006	387520101/1	UPPER STEERING COLUMN	£95.67	Add to
007	337394201/0	WING NUT	£13.64	Add to
008	387520105/1	LOWER STEERING COLUMN	£113.39	Add to
009	9710-0631-12	SQUARE NUT	£3.55	Add to
010	1134-5177-01	SLIDE COLLAR	£13.64	Add to
011	9595-0262-00	LOCATING PIN	£2.06	Add to
012	187593701/0	STEERING WHEEL KNOB	£48.11	Add to
015	112793301/0	HEX-HEAD SCREW M8 x 25	£2.06	Add to
016	112583500/0	WASHER M8 UNI 1751 WZ	£2.06	Add to
017	1134-6078-01	FLANGE WASHER	£5.87	Add to
018	1137-0055-01	LOWER SLIDE PLATE	£98.40	Add to
019	1134-6090-01	UPPER SLIDE PLATE	£99.76	Add to
020	1134-0240-00	SCREW	£9.14	Add to
021	9893-0616-16	SCREW M6 x 16	£2.47	Add to
022	387318251/0	BRAKE ARM	£32.99	Add to
023	1134-3262-01	SPRING	£8.73	Add to
024	112154510/0	LOW SELF-LOCKING NUT M6 UNI7474 ACC.6S	£2.06	Add to
039	387185100/0	ARM RESTS KIT	£216.66	Add to
040	1139-0011-01	SPEED NUT PLATE-ARM RESTS	£3.55	Add to
041	1139-0010-01	SCREW-ARM RESTS	£3.81	Add to
045	337592350/0	REAR SEAT TRAY [BLACK]	£28.90	Add to
046	112727801/0	SCREW TCB TORX M6 x 20	£2.06	Add to
