Transmission (1)

Transmission (1) assembly details for Stiga PRIMO (13-2411) 2011 model

Parts list

Match the number with the image on the left and click "Add" button to add the item to your basket

Please note, that the prices are for individual items

Items might appear more than once on the drawing, please check and adjust the quantity you require.

0011134-6613-01BEARING BOX & SHAFT ASSEMBLY£104.58 Add to
0029945-0825-16SCREW M6SF M8 x 25£3.15 Add to
0031134-9129-01BLADE BAR ASSEMBLY [2 PCS]£96.78 Add to
0041134-9130-01BLADE TIP KIT [2 PCS]£32.38 Add to
0051134-9054-01SHEAR BOLT KIT [6 x Bolts & Nuts]£9.17 Add to
0061134-6311-01BOLT 7/16" UNF£4.00 Add to
0071134-6312-01LOCK NUT 7/16" UNF£3.65 Add to
0081134-6211-01BLADE WASHER£4.28 Add to
0099997-1050-16SCREW M6S M10 x 50£3.65 Add to
0101134-6590-01MULCH PLUG£35.46 Add to
0119959-0820-16SCREW M6SF M8 x 20 TL£2.90 Add to
0121134-0341-01WASHER£7.56 Add to
0211137-1014-01TRANSMISSION COVER£35.28 Add to
0221134-0240-00SCREW£9.45 Add to
0249893-0616-16SCREW M6 x 16£3.28 Add to
0251134-9137-01TOOTHED BELT PULLEY [2 PCS]£59.81 Add to
0261134-6607-01BELT PULLEY£158.76 Add to
0279600-0168-01KEY£5.17 Add to
0281134-5124-02SPACER£5.92 Add to
0291134-5406-01WASHER M10 10.5 x 35 x 5£4.91 Add to
0309997-0850-16SCREW M6S M8 x 50£5.17 Add to
0311134-9133-01TOOTHED BELT£32.76 Add to
0321134-9136-01DECK DRIVE BELT£40.32 Add to
0349959-0820-16SCREW M6SF M8 x 20 TL£2.90 Add to
037112523060/0WASHER M8 8.4 X 24 X 2 (NOT USED ON STIGA MODELS)£2.90 Add to
