Transmission (2)

Transmission (2) assembly details for Stiga PARK PRO SVAN 4WD 2011 (13-6272-26) 2011 model

Parts list

Match the number with the image on the left and click "Add" button to add the item to your basket

Please note, that the prices are for individual items

Items might appear more than once on the drawing, please check and adjust the quantity you require.

RefNoDescriptionPrice
0011134-5700-01HYDRAULIC PUMP KPL-10ALP£845.53 Add to
0021139-1514-01HOUSING£743.66 Add to
0041139-1018-01SPRING£7.56 Add to
0051139-1527-01REPAIR KIT£933.66 Add to
0061139-1021-01CIRCLIP£2.90 Add to
0081139-1532-01RETAINING RING£4.37 Add to
0091139-0236-01BALL BEARING£38.08 Add to
0101139-1516-01PUMP SHAFT ASSEMBLY (INCL. 6-9)£232.85 Add to
0111139-1369-01CIRCLIP£4.37 Add to
0121139-1396-01SEAL£19.15 Add to
0131139-1022-01METAL THRUST£12.59 Add to
0141139-1523-01SWASH PLATE£151.35 Add to
0151139-1026-01THRUST PLATE£20.60 Add to
0161139-1024-01BEARING£26.20 Add to
0171139-1525-01THRUST PLATE£58.38 Add to
0181139-1509-01CYLINDER BLOCK KIT£232.85 Add to
0191139-1515-01CASE GASKET£13.73 Add to
0211139-1513-01VALVE PLATE£75.60 Add to
0221139-1166-01PIN£3.65 Add to
0231139-1368-01CHECK VALVE F£31.22 Add to
0241139-1374-01CHECK VALVE R£41.40 Add to
0251139-1366-01SPRING£4.59 Add to
0271139-1367-01CHECK PLUG£30.78 Add to
0281139-1530-01ROTOR SET£80.72 Add to
0291139-1529-01O RING£8.74 Add to
0301139-1533-01O RING£5.17 Add to
0311139-1107-01PLUG£7.42 Add to
0331139-1519-01PUMP BODY£708.73 Add to
0341139-1375-01CHARGE PLUG£40.61 Add to
0351139-1114-01O RING£3.15 Add to
0361139-1376-01SPRING£10.04 Add to
0371139-1389-01VALVE SPRING£6.43 Add to
0381139-1385-01RELIEF VALVE£25.84 Add to
0391139-1386-01CHARGE VALVE£23.43 Add to
0401139-1535-01BOLT W/WASHER£6.97 Add to
0411139-1536-01BOLT W/WASHER£6.97 Add to
0421139-1537-01BOLT W/WASHER£6.97 Add to
0431139-1538-01BOLT W/WASHER£6.97 Add to
0441139-1524-01SHIFT BLOCK£20.52 Add to
0461139-1365-01OIL SEAL£21.42 Add to
0471139-1393-01RING£4.37 Add to
0481139-1382-01WASHER£4.37 Add to
0511139-1127-01NUT£3.78 Add to
0521139-1102-01WASHER£3.65 Add to
0531139-1377-01PLATE (RETURN SPRING )£74.66 Add to
0541139-1378-01FULCRUM£86.84 Add to
0551139-1379-01ARM ( RETURN SPRING )£113.32 Add to
0561139-1380-01RETURN SPRING£47.44 Add to
0581139-1392-01RING£3.28 Add to
0591139-1381-01SET SCREW£7.56 Add to
0601139-1127-01NUT£3.78 Add to
0611139-1122-01BOLT W/WASHER£4.37 Add to
0621139-1372-01BY-PASS LEVER£57.56 Add to
0631139-1371-01BY-PASS ADAPTER£34.41 Add to
0651139-1115-01O RING£2.65 Add to
0661139-1373-01PLAT BY-PASS PLATE£7.57 Add to
0671139-1387-01RING BACK-UP RING£7.79 Add to
0681139-1112-01O RING£4.71 Add to
0691139-1370-01BY PASS PIN£40.08 Add to
0701139-1522-01WAVE WASHER£4.71 Add to
