Engine

Engine assembly details for Stiga SP 316 2018 model

Parts list

Match the number with the image on the left and click "Add" button to add the item to your basket

Please note, that the prices are for individual items

Items might appear more than once on the drawing, please check and adjust the quantity you require.

RefNoDescriptionPrice
001123878121/0SCREW 4.2 x 13£1.79 Add to
005118800189/0SELF-TAP SCREW 4.8 x 16£1.79 Add to
0382135030TORX SCREW M5 x 20£1.79 Add to
040123878021/0TORX SCREW M4 x 14£1.79 Add to
0692135040TORX SCREW M5 x 18£1.79 Add to
070118804730/0HEAT PROTECTION£3.15 Add to
071118804252/0OIL TANK CAP£5.45 Add to
076118804731/0ELECTRIC CABLE£2.06 Add to
077118804732/0ELECTRIC CABLE£2.06 Add to
078118804733/0WIRE CLIP£1.58 Add to
079118804734/0CRANKCASE£38.44 Add to
080118804735/0O RING 1.5 x 6.5£1.79 Add to
081118804736/0NOZZLE£2.86 Add to
085118804737/0GROMMET£1.79 Add to
086118804805/0CABLE COVER£2.87 Add to
090118804234/0CLIP£1.58 Add to
091118804740/0FUEL FILTER£4.99 Add to
092118804741/0CORRUGATED PIPE£2.06 Add to
093118804742/0CAP£1.79 Add to
094118804743/0SPIKE£3.15 Add to
095118804744/0INTERNAL PLATE£3.81 Add to
096118804745/0LEAD SCREW£1.79 Add to
097118804746/0CHAIN STOPPER£2.06 Add to
100118804747/0OIL PIPE£4.27 Add to
102118804749/0SPRAY NOZZLE£3.41 Add to
103118804750/0OIL PUMP£19.22 Add to
104118804751/0OIL PUMP COVER£1.79 Add to
105118550608/0WORM WASHER£1.79 Add to
106118804752/0WORM£3.15 Add to
107118804753/03/8 CLUTCH DRUM£15.69 Add to
108123235001/0NEEDLE BEARING 10X13X13£5.12 Add to
109118804818/0WASHER 8 x 26 x 1.5£2.06 Add to
114118804758/0CLUTCH£15.00 Add to
164118804853/0OIL PIPE SPRING£2.47 Add to
165118804800/0OIL FILTER ASSEMBLY£2.87 Add to
166118804801/0BREATHER VALVE ASSEMBLY£5.06 Add to
171118804820/0FUEL TUBE ASSEMBLY£13.77 Add to
