Deck lift

Match the number with the image on the left and click "Add" button to add the item to your basket

Please note, that the prices are for individual items

Items might appear more than once on the drawing, please check and adjust the quantity you require.

Ref	No	Description	Price
001	683-04155A	SHFT ASM:LIFT:LT-5	N/A	POA
002	712-04065	NUT	£4.02	Add to
003	716-0106A	RING E TYPE .625 DIA SHAFT	£3.33	Add to
004	720-0311	KNOB	£20.43	Add to
005	732-04225	SPR: TORSION:.290 ID X 1.95	£8.27	Add to
006	738-04130	SCR:SHLDR:.625x.175:3/8-16	£6.93	Add to
007	747-04282	HANDLE DECK LIFT LT-5	£26.10	Add to
008	747-04393	ROD:LIFT:13.68	£27.38	Add to
009	714-04040	PIN-COTTER	£4.38	Add to
010	783-04711C	ARM:LIFT:42" RT LH	N/A	POA
011	783-04494C	ARM:LIFT:42" RT RH (OBSOLETE)	N/A
012	741-0225	HEX FLANGE BEARING	£4.92	Add to
