Grass-Catcher

Grass-Catcher assembly details for Mountfield S461HP (20121602) 2012 model

Parts list

Match the number with the image on the left and click "Add" button to add the item to your basket

Please note, that the prices are for individual items

Items might appear more than once on the drawing, please check and adjust the quantity you require.

RefNoDescriptionPrice
001322785331/0DEFLECTOR SUPPORT [BLACK]£6.61 Add to
002122450464/0DEFLECTOR SPRING£2.08 Add to
003322109557/0DEFLECTOR FIXING [GREY]£4.52 Add to
003322109556/0DEFLECTOR FIXING [YELLOW]£4.59 Add to
004112728699/0SELF-TAPPING SCREW K60 x 22£1.96 Add to
005322600216/1DEFLECTOR [GREY]£13.37 Add to
005322600214/1DEFLECTOR [YELLOW]£12.34 Add to
006322393649/0GRASSCATCHER HANDLE [GREY]£5.72 Add to
006322393646/0GRASSCATCHER HANDLE [YELLOW]£5.33 Add to
007381486018/0GRASSCATCHER TOP-FULL INDICATOR [BLACK]£29.62 Add to
007322486264/0Grassbox Upper Part Yellow (OBSOLETE)N/A
008122608561/0GRASSCATCHER FRAME£12.61 Add to
009112728692/0SELF-TAP SCREW KA50 x 20£2.04 Add to
010322545159/0FIXING PLATE£1.96 Add to
011181002318/0GRASSBAG [BLACK]£36.61 Add to
