WHEEL SUSPENSION

WHEEL SUSPENSION assembly details for Mountfield SP470 2005 model

Parts list

Match the number with the image on the left and click "Add" button to add the item to your basket

Please note, that the prices are for individual items

Items might appear more than once on the drawing, please check and adjust the quantity you require.

RefNoDescriptionPrice
272322735557/0HEIGHT ADJUST QUADRANT£3.83 Add to
273112293201/0HEXAGON NUT M8 WITH EXAGONAL FLANGE£2.06 Add to
2749838-9516-12SCREW K50 x 16£2.47 Add to
275112728689/0SCREW KA50 x 12£1.79 Add to
276122131750/0NUT M8£2.06 Add to
278381003306/0HEIGHT ADJUST LEVER£6.69 Add to
279322600170/0INNER WHEEL COVER D=165£10.49 Add to
280122524324/0SHOULDER BOLT£4.52 Add to
281122671651/0WASHER 8.3 x 22 x 2£2.32 Add to
282322034509/0PLASTIC BUSH [BLACK]£1.91 Add to
283322686091/1WHEEL D=165mm£7.10 Add to
284122524322/0SHOULDER BOLT£4.78 Add to
285322110312/0HUB CAP 165/175 (6 SPOKES) GREY£10.09 Add to
287381003303/0REAR HEIGHT ADJUST LEVER£17.86 Add to
288322600106/1INNER WHEEL COVER D=190£7.10 Add to
289112521370/0WASHER M12 13 24 x 2.5£2.06 Add to
2901111-1273-01Bushing (OBSOLETE)N/A
291381007355/0REAR WHEEL 190mm£17.59 Add to
292112523050/0WASHER M6 6.6 x 24 x 2£2.06 Add to
293112735599/0SELF-TAPPING SCREW M6 x 16£2.06 Add to
294322110346/0HUB CAP 190 (6 SPOKES) GREY (OBSOLETE) (OBSOLETE)N/A
401122033393/0REAR WHEELS AXLE£26.18 Add to
402181003078/0GEAR BOX F.R. ES/ESL£211.50 Add to
405122450432/0TENSION SPRING£2.06 Add to
406122753001/0PIN D=4 x 32£2.06 Add to
407122122202/0BEARING D12£2.47 Add to
408112622620/0CYLINDRICAL PIN D=4 x 20£1.79 Add to
410122076645/0DRIVE KEY 4 x 8 x 15£2.06 Add to
411122570125/0RIGHT/LEFT PINION GEAR£15.00 Add to
412322160520/0DUST COVER£2.06 Add to
413112608520/0CIRCLIP D=11£2.54 Add to
414135064000/0TRAPEZOIDAL BELT ZX27 1/2£12.00 Add to
415122601912/0PULLEY D=67 F.R. GEAR BOX£31.89 Add to
416112645705/0ROLL PIN D=5 x 32£2.02 Add to
