WHEEL SUSPENSION

WHEEL SUSPENSION assembly details for Mountfield PWR SP 410PRMA 2005 model

Parts list

Match the number with the image on the left and click "Add" button to add the item to your basket

Please note, that the prices are for individual items

Items might appear more than once on the drawing, please check and adjust the quantity you require.

RefNoDescriptionPrice
3011117-1380-01Wheel shaft (OBSOLETE)N/A
30222785135/0LEVEL WHEEL SUPPORT EP420 2009 (OBSOLETE)N/A
303322735555/0WHEELS ADJUSTMENT SECTOR EP420£8.32 Add to
304381003306/0HEIGHT ADJUST LEVER£6.69 Add to
305322600170/0INNER WHEEL COVER D=165£10.49 Add to
3069675-0017-02STARLOCK£2.18 Add to
307112293201/0HEXAGON NUT M8 WITH EXAGONAL FLANGE£2.06 Add to
308122671651/0WASHER 8.3 x 22 x 2£2.32 Add to
309322034509/0PLASTIC BUSH [BLACK]£1.91 Add to
310322686091/1WHEEL D=165mm£7.10 Add to
311122524322/0SHOULDER BOLT£4.78 Add to
312322110320/1HUB CAP D=165 (3 SPOKES) WHITE£6.39 Add to
313112728690/0SELF-TAP SCREW KA50 x 25£0.79 Add to
31422735567/0WHEEL ADJ SECTOR EP434 2008£8.70 Add to
3151136-1870-01Wheel plate (OBSOLETE)N/A
316112728689/0SCREW KA50 x 12£1.79 Add to
317381003303/0REAR HEIGHT ADJUST LEVER£17.86 Add to
318322600106/1INNER WHEEL COVER D=190£7.10 Add to
319112521370/0WASHER M12 13 24 x 2.5£2.06 Add to
3201111-1273-01Bushing (OBSOLETE)N/A
321381007355/0REAR WHEEL 190mm£17.59 Add to
322112523050/0WASHER M6 6.6 x 24 x 2£2.06 Add to
323112735599/0SELF-TAPPING SCREW M6 x 16£2.06 Add to
3241111-2815-03Hub cap-white (OBSOLETE)N/A
401122033393/0REAR WHEELS AXLE£26.18 Add to
4021136-1878-01Transmission (OBSOLETE)N/A
405122430216/0TENSION SPRING£10.09 Add to
406122753001/0PIN D=4 x 32£2.06 Add to
407122122202/0BEARING D12£2.47 Add to
408112622620/0CYLINDRICAL PIN D=4 x 20£1.79 Add to
410122076645/0DRIVE KEY 4 x 8 x 15£2.06 Add to
411122570125/0RIGHT/LEFT PINION GEAR£15.00 Add to
412322160520/0DUST COVER£2.06 Add to
413112608520/0CIRCLIP D=11£2.54 Add to
414135063800/0TRAPEZOIDAL BELT Z 27 LP=710(BRONZE GEAR)£11.01 Add to
415122601909/0PULLEY£6.01 Add to
416112645705/0ROLL PIN D=5 x 32£2.02 Add to
