Crankcase

Crankcase assembly details for Mountfield MC382 2008 model

Parts list

Match the number with the image on the left and click "Add" button to add the item to your basket

Please note, that the prices are for individual items

Items might appear more than once on the drawing, please check and adjust the quantity you require.

RefNoDescriptionPrice
0013614740BRAKE BAND£7.92 Add to
0022312100FLAT WASHER D=4X12X1,5£1.79 Add to
0032123060SELF-THREAD SCREW£1.79 Add to
0044252310CHAIN BRAKE LEVER£17.04 Add to
0053180500Roller 5X19,8£4.01 Add to
0063614780Spring£7.19 Add to
0073750117BRAKE COVER [GREY]£9.85 Add to
0082123100SCREW M4 8 x 13£1.79 Add to
0093654420Spring£7.19 Add to
0103614490BRAKE BLADE PLATE£2.74 Add to
0113180510Roller 6X21,8£4.01 Add to
0123614330Bush£7.19 Add to
0142123030TORX SELF-THREAD SCREW£1.79 Add to
0154252613ASS.COPRICILINDRO 370410 ROSSO£33.53 Add to
0164563770HAND GUARD£27.27 Add to
0178781610AIR FILTER£14.05 Add to
0193750450PRIMER BUTTON£2.87 Add to
0203654430SPRING£1.79 Add to
0213750440AIR PURGE BUTTON£3.69 Add to
